| MODEL NO. |
TP-1500.2D |
| TYPE (FREQUENCY) |
WIDE RANGE |
| CHANNEL |
2 |
| OPERATING VOLTAGE (DC) |
9-15V |
| OUTPUT POWER (@14.4V/1 OHM) |
1500W * 2 |
| OUTPUT POWER (@14.4V/2 OHM) |
770W * 2 |
| OUTPUT POWER (@14.4V/4 OHM) |
400W * 2 |
| INPUT SENSITIVITY |
0.2-6V |
| SIGNAL TO NOISE RATIO |
≥ 95 dB |
| FREQUENCY RESPONSE |
10 - 10000 Hz |
| LOW PASS FILTER |
35 - 10000 Hz |
| SUBSONIC FILTER |
10 - 1000 Hz |
| HIGH PASS FILTER |
|
| PHASE REGULATION |
0 - 180° |
| MINIMUM LOAD ON SINGLE CHANNEL |
1 OHM |
| MINIMUM LOAD IN BRIDGE MODE |
2 OHM |
| MINIMUM LOAD IN LINK MODE (MASTER/SLAVE) |
UNLINKABLE |
| SIZE (L*W*H) |
510*255*63MM |
| WEIGHT(KGS) |
9.5KGS |
